Parallax Volumetric Additive Manufacturing
No Layers. No Supports. No Assembly. P-VAM cures photoreactive resin simultaneously across three dimensions, manifesting complete objects in one continuous step.
Unprecedented Voxel-Level Control
Our sophisticated algorithms coordinate multiple rays sources to cure photoreactive resin simultaneously across three dimensions. Unlike traditional additive that builds layer by layer, P-VAM creates the entire geometries at once.
Native optical resolution isn’t fixed—even across a single part. The system automatically optimizes light placement and configuration based on feature requirements, enabling unprecedented design flexibility.
Solving Manufacturing’s Biggest Problems
10-100x Faster Production
- Minutes instead of hours for complex parts
- Built for 24/7 manufacturing environments
- Scales to serial production where traditional 3D printing hits walls
- No print farm bottlenecks
Impossible Geometries Made Possible
- Overprint and embed objects directly within components
- No support structures required
- Complex internal channels and lattices
- Fully solid parts without layer adhesion issues
From Toolhead to Production Line
- Modular form factor integrates directly into assembly lines
- Eliminates separate pre-production additive steps
- Seamless workflow integration
- Adaptive to existing manufacturing processes
Designed for Production Scale
P-VAM architecture breaks free from their paradigm. Our modular toolhead approach enables direct integration into existing production lines, with nearly unlimited scalability in X-Y dimensions as a factor of minimum feature size.
Automated configuration optimizes performance for each specific application, from benchtop evaluation to full production integration.
Evaluation Kit vs Future Production Capabilities
Capabilities | P-VAM Evaluation Module | Future Production Capabilities |
|---|---|---|
Build Method | Volumetric with Parallax Beamlets | Volumetric with Parallax Beamlets |
Form Factor | Desktop: 66cm x 61cm x 56cm | Modular Toolhead: Fully Customizable |
Build Volume | 75 x 75 x 10mm | Unlimited X-Y, height scales with feature size |
Optical Resolution | ~22µm | As small as 1 µm |
Feature Size | 250 µm | ~40µm with 10mm depth, 2-3 um with 20-30mm depth |
Light Source | 405 nm laser | Customizable laser range |
Material Profiles | Arkema HT511 | Open ecosystem with custom profiles |
Sofware | P-VAM Simulation Suite | Enterprise features, 3rd party integration |
Open Materials, Aligned Business Model
P-VAM supports any transparent photopolymer regardless of viscosity. We’re building an open ecosystem of material partners, not locking customers into proprietary consumables.
Simple tier-based pricing model that improves with scale, no per print fees that punish manufacturing growth.
Complete Software Solution
P-VAM Simulation Suite
Load standard 3D files and execute volumetric builds in real time. Built for manufacturing professionals and serial production, not print farms.
Production Integration
Cloud infrastructure handles complex calculations while APIs connect directly to existing manufacturing execution systems and workflows.
Continuous Updates
Regular software enhancements, material profiles, and optimization algorithms delivered automatically to keep your systems current.
Ready to Explore Production- Scale Additive?
Join leading manufacturers exploring how P-VAM technology can solve their most challenging production problems. Our evaluation module provides hands-on experience with breakthrough capabilities.
